Three Channel Physiograph
3 channel digital student physiograph with TFT and couplers.
₹1.45 lakh – ₹1.75 lakh
Student Digital Physiograph (Single Channel) – Overview
The Student Digital Physiograph is an indigenous single-channel recorder designed for undergraduate physiology and pharmacology practicals. A standalone colour TFT display (15.5 × 9.5 cm) shows traces with time and event marks, and an optional USB interface lets students save, analyse and print experiments on a PC.
Six couplers are built into one unit — biopotential, ECG, strain gauge, pulse-respiration, temperature and isotonic — and the system accepts eight transducer types including force, pressure, volume and respiration belt. It records ECG, EEG, EMG, ENG, muscle force, BP, pulse, respiration and temperature for human and animal studies.
The unit can later be expanded to two or three channels. We supply complete lab kits with transducers, demo and faculty training.
Key Features
- Indigenous digital physiograph with time and event channel
- Standalone TFT display with optional USB PC interface
- Compact, portable, beginner-friendly design
- Six couplers in one unit
- Supports eight transducer types
- Data storage and review on the TFT screen
- Printing and analysis software for PC
Technical Specifications
| Channels | 1 (expandable to 2 or 3) |
|---|---|
| Display | Coloured TFT, 15.5 × 9.5 cm |
| Channel width | 80 mm |
| Recording parameters | ECG, EEG, EMG, ENG, muscle force, BP, pulse, respiration, temperature |
| Interface | USB to PC |
| Applications | Human & animal studies |
| Certification | CE & CDSCO approved |
| Warranty | 1 year |
Specifications are as published by the manufacturer and may change with model updates. Manufacturer spec sheet (PDF).
Applications
- Experimental physiology (human and animal)
- Pharmacology studies in medical colleges
- Neuroscience and life-science research
- Teaching demonstrations in physiology labs
- Clinical training and student experiments
Warranty, Installation & Support
- 1-year manufacturer warranty
- Onsite installation, demo and operator training
- Online and onsite technical assistance
- Genuine spare parts with warranty compliance
- GeM, tender and institutional purchase documentation
- Export to Nepal, Bhutan and Bangladesh (IEC registered)
Looking for local supply? See Advanced Physiograph Machines Across India: RS Health Supplies or our service network.
Student Digital Physiograph (Single Channel) – FAQs
What is the price of a student physiograph?
The single channel digital student physiograph is ₹90,000 (ex-GST); the three channel model is ₹1,45,000.
Can it be upgraded?
Yes, it is expandable to two or three channels.
Which transducers are supported?
Force, pressure, volume, respiration, temperature, pulse, respiration belt and isotonic transducers.
Is it CDSCO approved?
Yes, it is CE and CDSCO approved.
