12 Channel ECG Machine – Overview
The Maestros 12 Channel ECG is a portable interpretive electrocardiograph for hospitals, nursing homes, diagnostic centres and medical colleges. It acquires all 12 standard leads simultaneously and prints full A4 reports in 3-lead, 6-lead or 12-lead formats on a 210 mm thermal printer.
A 5-inch colour touch display (800×480) makes patient entry and review simple, while auto and manual modes, ECG interpretation and arrhythmia detection support quick decisions. The 11.1 V, 4400 mAh Li-ion battery records around 500 ECGs per charge, and data can be downloaded to a PC or memory stick or sent to the cloud over Bluetooth/GSM.
We also supply single-channel, 3-channel, 6-channel and PC-based 12-channel ECG machines. Maestros units are running at AIIMS Guwahati, AIIMS Kalyani, Ispat Hospital Rourkela, CIP Ranchi and Gauhati Medical College.
Key Features
- Full 12-lead ECG with A4 printing
- 5" colour touch display (800×480)
- Auto and manual modes
- 3L / 6L / 12L print formats
- Interpretation, measurement and arrhythmia detection
- Touch-screen patient data entry
- PC and memory-stick download; optional cloud via BT/GSM
- Rechargeable Li-ion battery — ~500 ECGs per charge
- Internal storage for 25 patients
Technical Specifications
| Leads | 12 standard |
|---|---|
| Modes | Auto / manual |
| Display | 5" TFT colour touch, 800 × 480 px |
| Frequency response | 0.05 – 150 Hz |
| Sweep speed | 12.5 / 25 mm/s |
| Sensitivity | 5 / 10 / 15 / 20 mm/mV |
| CMRR | 105 dB |
| Input impedance | > 10 MΩ |
| Storage | 25 patients |
| Printer | 210 mm thermal (A4 formats) |
| Battery | 11.1 V, 4400 mAh Li-ion (~500 ECGs/charge) |
| Dimensions | 308 × 240 × 80 mm |
| Weight | 2.73 kg |
| Accessories | Patient cable, electrode set, USB power cable, manual, calibration certificate |
| Warranty | 12 months from installation |
Specifications are as published by the manufacturer and may change with model updates. Manufacturer spec sheet (PDF).
Applications
- Cardiology and general hospitals
- Nursing homes and diagnostic centres
- Clinics and diagnostic labs
- Medical and nursing colleges
- Research and occupational health screening
Warranty, Installation & Support
- 1-year manufacturer warranty
- Onsite installation, demo and operator training
- Online and onsite technical assistance
- Genuine spare parts with warranty compliance
- GeM, tender and institutional purchase documentation
- Export to Nepal, Bhutan and Bangladesh (IEC registered)
Looking for local supply? See ECG Machine Range or our service network.
12 Channel ECG Machine – FAQs
What is the price of a 12 channel ECG machine?
The Maestros 12 Channel ECG costs ₹75,000 + 18% GST (₹13,500) = ₹88,500. Other 12-channel models range from ₹60,000 to ₹1 lakh.
Do you have PC-based ECG?
Yes. A PC-based 12 channel ECG, as well as single, 3 and 6 channel models, are available.
How many ECGs can it take on one charge?
About 500 ECGs on the 11.1 V, 4400 mAh Li-ion battery.
What warranty is included?
12 months from the date of installation, plus onsite installation and demo.
Are these ECG machines CE certified?
Yes, all models are CE and CDSCO approved.
